Item code: BH179

Glow and EP

SPECIFICATION:

–  Wingspan: 2,350mm (92.5 in).

–  Length:  1,880mm (74 in).

–  Weight:  9.4 kg (20.7 lbs).

–  Wing area:  98.5dm2.

–  Wing loading: 95.4 g/dm2.

–  Wing type: Naca Airfoil.

–  Servo mount: 42mm x 21mm.

–  Gear type: Aluminium Hi-grade for main gear and tail gear (included).

Parts listing required (not included):

–  Radio: 05 channels.

–  Servo: 6 standard high torque servos.

–  Engine: 60 cc gas.

–  Motor: Brushless outrunner 5000 –  6500W, 230KV.

–  Propeller: Suit with your engine.

Recommended motor and battery set up (not included):

–  Motor:  RIMFIRE. 50 cc.
–  Lipo cell: 12 cells 5500 – 6000mAh.

–  Receiver battery: 6.0V 2400-2600mAh(2 Packs).

–  ESC: 120A.

ALL BALSA – PLY WOOD CONSTRUCTION.
COVERED IN A HEAT-SHRINK FILM WITH PRINTED.
