Type
Scale 1/10th
Brushed/Brushless BL
Sensored/Sensorless SD
Waterproof No
Specifications
Cont./Peak Current 100A/500A
Input Voltage 2S Lipo
BEC BEC Output Switch Mode 6V/7.4V @5A
Wires & Connectors
Input Wires Black-13AWG-200MMmm*2
Output Wires Black-13AWG-200MMmm*3
Input Connectors No
Output Connectors No
Fan
Size 20*20*8mm
Voltage Range 5-7.4V
Powered by BEC
ESC Programing via
SET Button on ESC Not Supported
LED Program Box Not Supported
LCD G2 Program Box Supported
LCD PRO Supported
OTA Programmer Supported
Program Port Separate Program Port
Data Recording
Extreme value Supported
Real-time Data Supported
Historical data (Graph) Supported
Firmware
Firmware Upgrade Supported
Size & Weight
Size 34.8*30*13.8mm
Weight 63g(w/Wires)
Applications
Motors 3650 size motors
Vehicles Stock Class of 1/10th Touring Car and Buggy Racing, 1/10th Drift
KV Rating/T Count ≥10.5T

(HW30112402)

SKU HW30112402
Brand HOBBYWING
